GDT Automatic Pretreatment Chemical Spray Machine
*Suitable for Spraying Chemical material to fabric for pretreatment,for purpose improving wrinkle-free or fleece finishing effect.
*Adopt Intelligent PLC Controler & System,Could be set for spraying action,time,flow and steps ETC.
*Professional High Quality Spray heads,for best mist result and more uniform chemical absorbing result
*Installed with direct steam spraying action
*With Invertor control,drum speed adjustable for various effects demands
*Inner & Outer Drums and Critical Connection Parts are made of stainless steel.
Cylinder Size:Φ970×970 Cylinder Rotational Speed:32r/min
Cylinder Capacity:45kg Rated Steam Pressure:0.4-0.8Mpa
Main Motor:1.1kw Ventilator Motor:1.1kw
Heating Mode:Steam Dimension:1570×1100×2160mm
Weight:500kg
| Model | GDT-100 | GDT-150 | GDT-200 |
| Capacity | 13 | 22 | 36 |
| Cylinder Size | Φ970×970 | Φ1150×970 | Φ1400×1070 |
| R.P.M. | 32 | 32 | 28 |
| Thickness of Cylinder | 1.5 | 1.5 | 2 |
| Motor Power | 1.1 | 1.1 | 2.2 |
| Exhaust power | 1.1 | 1.5 | 2.2 |
| Steam pressure | 0.4-0.8mpa | ||
| diamension | 1570*1100*2160 | 1600*1250*2280 | 1800*1530*2500 |
| net weight | 500 | 550 | 650 |
